90 Kva Vertical Spot Welding Machine

‹ ›

Ask For Price

Min. Sipariş 1 Piece

Advertisement No:	#00239493
Category:	Vertical Point Welding Machine
Brand:	Fast Makina
Model Type:	FMP - 90KVA
Product Type:	For Sale
Product Status:	New
Origin:	Turkey
Delivery Status:	In stock
Location:	Orhangazi Mah. / Esenyurt / İstanbul
Sales Detail:	Bank Transfer, Negotiated

Contact the seller

Fast Makina

Fast Makina ve Otomasyon Sistemleri San. Tic. Ltd. Şti.

Advisor : Fast M.

Contact
Send Message

+90 266 690 79 20

+90 537 288 97 78

Go to the store All Ads

Purchasing Tips

Protect your privacy, review the product descriptions...

Fast Makina FMP - 90 KVA 90 kVA Vertical Spot Welding Machine

Pneumatic, microprocessor, water-cooled 2 phase 400v/50Hz Standard Vertical Spot Welding Machines

Usage areas:
Automotive
Household appliances
Defense industry
Electricity and lighting
billboard makers
shelf industry
* Fixtures and molds are made on the machine according to the work situation.

FMP - 90KVA Technical Specifications:

	FMP - 90KVA
Rated power	90 KVA
Rated current	225 A
Secondary voltage	7.2 V
Arm size	300/500 mm
Piston diameter	ø125
Electrode pressure force	850 daN
Air pressure	2/8 bar
Cooling water inlet pressure	2/5 bar
Cooling water inlet temperature	15/25 §C
Cooling water inlet flow rate	15 lt/dk
Delayed mains fuse	160 A
Supply cable (up to 5 meters)	2x50+6
Machine dimensions(WxLxH)	720X1280X2000

Standard Machine Features

Microprocessor control card
air conditioner
Air tank
T electrode
Protected foot pedal
Emergency stop button
Piston with special bearing
Bottom table lifting jack

Optional Features

Control unit with current reading
proportional pressure regulator
double hand button
Burr protection curtain
light barrier
special molds
Approach piston
special electrodes
