180 m2/Hour (5 Disk 1 Roller) Carpet Washing Machine 1 / Video

The Prado 5003 carpet washing machine, manufactured by Karaçaylı Makina, is a top-of-the-line machine designed for industrial cleaning needs.

The chassis of the Prado 5003 is made of galvanized or chrome material to ensure durability and longevity. Galvanized and chrome materials are commonly preferred in industrial equipment due to their superior resistance to corrosion. Therefore, the Prado 5003 can perform excellently even in challenging working conditions and is resistant to rust.

Control and Speed

The machine is equipped with a user-friendly control system, either PLC or a touchscreen panel. This allows operators to easily control all functions of the machine. The speed control feature enables operators to adjust suitable speeds for different types of carpets, contributing to the longevity of both the machine and the carpets.

Detergent and Water System

The Prado 5003's automatic detergent and water system allow users to adjust detergent quantity and water flow precisely. This ensures optimal use of detergent and water during the cleaning process, reducing costs and providing an eco-friendly cleaning experience.

Pressurized Rinsing

The machine's pressurized rinsing system ensures thorough cleaning even in the deepest corners of the carpets. Pressurized water penetrates the carpet fibers, effectively removing dirt and detergent residues.

Rolling and Easy Transportation

The rolling feature ensures that carpets are neatly rolled after cleaning, facilitating easier transportation and storage. Additionally, the carpet transportation cart enables easy transportation of carpets, particularly advantageous when working with large-sized carpets.

Washing Performance and Capacity

With the lower washing roller brush, effective cleaning is provided up to the bottom of the carpet. This machine, powered by 380V operating voltage, easily handles tough cleaning tasks. With a washing belt width of 320 cm, the Prado 5003 can effortlessly clean even large carpets.

Physical Features

The machine dimensions are designed as 380 x 300 x 150 cm, indicating that the Prado 5003 is a large-sized machine suitable for industrial use. With a weight of 1750 kg, it demonstrates a sturdy and durable structure.

Cleaning Capacity and Motor Power

The Prado 5003 has a washing capacity of 180 m²/hour, indicating that the machine can meet intensive cleaning demands. With 5 disk brushes and 1 roller, carpets are thoroughly cleaned from all directions. The 10 kW motor provides sufficient power for operations requiring high power.

Prado 5003 Technical Specifications:

• Chassis: Galvanized or chrome production
• Control: PLC or touchscreen panel
• Speed Control
• Automatic Detergent and Water System
• Pressurized Rinsing System
• Rolling Feature
• Detergent Tank
• Carpet Transportation Cart
• Lower Washing Roller Brush
• Operating Voltage: 380V
• Washing Belt Width: 320 cm
• Machine Dimensions: 380 x 300 x 150 cm
• Machine Weight: 1750 kg
• Washing Capacity: 180 m²/hour
• Brush Count: 5 disk + 1 roller
• Motor Power: 10 kW
